Technical Specification

  • Print Area: Edge to Edge
  • Card Feeding: Automatic
  • Card Size: ISO CR80
  • Card Thickness: 0.38mm (15mil)- 0.76mm (30mil)
  • Card Type: PVC, PET, Composite PVC
  • Monochrome: 5 sec./card (720 cards/hour)
  • YMCKO: Max. 20 sec./card (180 cards/hour)
  • Memory: 64MB RAM
  • Control Panel: 1 LED Button
  • Power Supply: DC 24V
  • Power Consumption: 48W
  • Temperature/Humidity: 15~35ºC/35~70%
  • Certifications: CB, CE, FCC, KC, CCC

Highlights

  • Elevate your Print Quality w/ FINE™ Imaging Technology
  • 300dpi (Color), 600, 1200dpi (Mono only)
  • Edge-to-Edge Full Color Printing
  • Entry-Mid Range Dye-Sublimation Printer
  • Automatic Card Feeding
  • Over 180 Cards per Hour
  • Upgradeable to Duplex
  • 3-Year Advance Exchange Warranty

Encoding Options

  • Magnetic Encoding (Read/ Write, HiCo/ LoCo), JIS II)
  • Contacless Encoding (DESFIRE, iCLASS, Prox*)
  • Contact Encoding (ISO 7816 (ID-1))

Communication

  • Ethernet
  • USB

Supported Platforms

  • Windows
  • Linux
  • Mac OS

Resolution

300 DPI
